start a family ride
where fun and joy collide.
Minivan SE
Motor Type
Mid-drive Motor
Rear Hub Motor
Peak Torque
130NM
90NM
Max Range
120 Miles(193 Km)
40 Miles(64 Km)
Drive System
Gates Belt CDX
High-strength Steel Chain
Shifting System
Enviolo Twist Shifter
Shimano 8-Speed Shifting System
Max Load
450 lbs
450 lbs
Additional Battery
Smart Anti-Theft
Ride with Ease, Unparalleled Performance
smart app companion
Technical Details
Specifications
Core performance, battery, drivetrain, safety, and component details for the Minivan platform.
Powertrain
Motor
Ananda Cargoline torque sensing mid motor
500W rated power, peak 750W
For the Canadian market, this model is configured with a 500W motor.
130 Nm of torque
500W rated power, peak 750W
For the Canadian market, this model is configured with a 500W motor.
130 Nm of torque
Pedal Assist
Intelligent 5 level pedal assist. Throttle on demand
Speed
Class 2: 20mph
Max speed up to 27mph
For the Canadian market, the maximum speed is 32 km/h.
Max speed up to 27mph
For the Canadian market, the maximum speed is 32 km/h.
Controller
48V, 20 amps
Battery & Charging
Battery
Default built-in 48V/14AH battery
48V/14AH powered by 18650 LG cells
48V/14Ah, 48V/25Ah optional additional lithium battery powered by 18650 LG cells
Safety assurance with UL certification
48V/14AH powered by 18650 LG cells
48V/14Ah, 48V/25Ah optional additional lithium battery powered by 18650 LG cells
Safety assurance with UL certification
Dual Battery Balancer
Custom 42-60V dual battery balancer
Charger
48V, 3 Amp smart charger, 3 Pin Ports
Display & Connectivity
Display
Smart color display
With IOT integrated
Backlit LCD with USB charger
GPS tracking available
Letrigo Custom App compatible
On-the-air update with latest software
With IOT integrated
Backlit LCD with USB charger
GPS tracking available
Letrigo Custom App compatible
On-the-air update with latest software
Lighting & Safety
Lights
Front: LED front light
Rear: Star Union WD400 Tail/Brake Light
Downtube light strip: Light strips on both sides, multiple colors, controlled by app, LED with turning light
Rear: Star Union WD400 Tail/Brake Light
Downtube light strip: Light strips on both sides, multiple colors, controlled by app, LED with turning light
Brake Calipers
Tektro Hydraulic 4 Pistons, HD-E725, heavy duty brakes
Brake Levers
Forged aluminum, 2 finger levers, with power cut-off when braking
Brake Rotors
180mm front and rear
Drivetrain
Belt Drive System
Gates Belt CDX
Crank Set
Gates, 170mm cranks
Shifter
Enviolo twist shifter
Frame & Chassis
Fork
Suspension hydraulic fork, 6061 aluminum, 60mm travel
Frame
6061 aluminum, heavy duty design
Handlebars
Promax 31.8mm × 720mm, aluminum
Headset
Sealed bearing, aluminum
Kickstand
Center mount, dual kickstand, aluminum
Pedals
Wellgo, aluminum platform
Stem
JCK JY-DB530-8, aluminium adjustable stem
Wheels, Contact Points & Weight
Rims
24" Aluminum alloy, double wall, 36H
Tires
CHAOYANG Cargo tires 24" × 2.6" with Tanwall
Saddle
Velo, VL-6318NP1, soft gel
Seat Post
Promax, 30.9mm × 300mm
Seat Post Clamp
Gineyea, 34.9mm, aluminum
Spokes
13-gauge stainless steel, black
Net Weight
71lbs
Load Capacity
Total Load Capacity
450lbs
Rear Seat Load Capacity
140lbs
